| Print Heads Type | KYOCERA KJ4B-0600-020SQ (Katana) |
|---|---|
| No. Print Heads | 80 |
| No. Printing Resolution | 600 DPI |
| Printing Width | 3400 |
| Printing Engine (Provided by MAS) | XCD2025_GD25 |
| Level of inks coverage | 6 |
| No. Printing Mode | 42 |
| Level of Grey | 16 |
| Drops Size | 4 -> 96 pl |
| Maximum Speed with 8 Colours | 2500 sqm/hour |
| Maximum Speed with 2 x CMYK | 3400 sqm/hour |
| Level of inks coverage |
Coverage (ml/sqm x color) （ml/sqm） |
Max drop size |
|---|---|---|
| A | 8,9 | 16 |
| B | 13 | 24 |
| C | 17,8 | 32 |
| D | 26,7 | 48 |
| E | 35,6 | 64 |
| F | 52 | 96 |
